Description
Rosemount™ 326P Pressure Transmitter
The Rosemount 326P Pressure Transmitter is specifically engineered for pressure and hydrostatic level applications in the food and beverage industry. A variety of industry standard process connections, hygienic certifications (3-A, FDA, EC 1935, etc.), a polished stainless steel housing, and the ability to withstand clean-in-place processes enable the transmitter to meet your process requirements while minimizing contamination risks and assuring product safety.
Specifications
- Accuracy
- 0.20%
- Communication Protocol
- 4-20mA, Switch
- Rangedown
- 4:1
- Measurement Range
- Up to 360 psig (24,8 bar)
- Process Temperature
- Up to 257°F (125°C); 293°F (145°C) for a maximum of 1 hour
- Process Wetted Material
- Ceramic, PTFE, 316L SST Polished to Ra < 16 µ-in. (0.4 µ-m)
- Diagnostics
- Basic diagnostics
- Certifications/Approvals
- 3-A, FDA, EC 1935, EC 2023, see product data sheet for complete list of certifications
Features
- G1" process connection is compatible with full suite of hygienic process connection adapters
- Compact form factor enables installation in applications with space constraints
- M12 electrical connector allows for simple installation and start-up
- Local Operator Interface (LOI) for simple, local commissioning on-site without the use of extra tools
- Configurable switch output for indication of abnormal pressure conditions
- Designed to withstand CIP processes as well as external
